    Fertilizer Industry 0.75KW 20kg Check Weigher Machine

    Ask Lasest Price
    Brand Name : EAGLE
    Model Number : SCW-A/B/C
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 200 units/month
    Delivery Time : 8-15 working days after deposit
    • Product Details
    • Company Profile

    Fertilizer Industry 0.75KW 20kg Check Weigher Machine

    Fertilizer Industry Check Weigher Machine Steel Galvanization , Check Weigher Indicator


    Brief Introduction


    Check weigher substantiates the extensive know-how that the company has accumulated in weighing technology over the years. By including a high-precision weight checking function in the production line, your product quality can improve without any decline in efficiency. The series provides a whole range of features for handling different products, and incorporate new functions in response to modern necessities.


    Machine Parts List


    No.NameBrand/ModelMaterial
    1MotorCPGAluminum (shell)
    2BeltZhenjiePVC
    3Bearing blockLKCast iron
    4OutriggerSquare tube 50x50Carbon steel spray
    5Beam frameBending plate, thickness 3mmStainless steel
    6Main rollerEagle, Diameter φ58Carbon steel spray anti-rust paint
    7Driven rollerEagle, Diameter φ58Carbon steel spray anti-rust paint
    8GuardrailBent plate, thickness 1.5mmStainless steel 201
    9Touch screenSaimo
    10SensorHBM

    Machine Features


    Report and Data Exportation: Built-in real time report, exportable to Excel file, storing up 1 year production data in USB disk

    Connectivity: standard ports for data exportation and connect to PC

    Self-learning: no need to calibration, system will find the best set up for the product. Configurable up to 2000 product settings

    Different Detection Modes: Default Mode, Static Mode, Power saving mode

    Faulty report: The system can detect and report faulty part of the system makes it easy to diagnose problems

    Output Ports: RS-485 and RS-232, able to Connect with printers and label machines


    Technical Parameters


    ModelSCW-160SCW -230SSCW -230LSCW -300SCW -400SCW -500
    Detecting Range10~600g20~2000g20~2000g20~5000g0.2~10kg0.5~20kg
    Scale Interval0.05g0.1g0.1g0.2g1g1g
    Accuracy±0.1g±0.2g±0.2g±0.5g±1g±2g
    Detecting Speed (Max speed)250pcs/min200pcs/min155pcs/min140pcs/min105pcs/min75pcs/min
    Belt Speed70m/min70m/min70m/min70m/min70m/min60m/min
    The weighed product sizeWidth150mm220mm220mm290mm390mm490mm
    Length200mm250mm350mm400mm500mm700mm
    Weigher platform sizeWidth160mm230mm230mm300mm400mm500mm
    Length280mm350mm450mm500mm650mm800mm
    Operation Screen12-inch Touch LCD Screen
    Product Storage Quantity100 kinds
    Segments Number of Sorting2 or 3
    RejecterRejecter Optional
    Power Supply220V (Optional)
    Degree of ProtectionIP30/IP54/IP66
    Body MaterialStainless Steel (SUS304)

    Our Service


    1. one-year guarantee for whole machine

    2. 24 hours technical support by e-mail

    3. calling or door-to-door service


    FAQ


    Q: How to select the suitable weight checking machine type for your product:

    A: Please contact with our people and tell us information: your product sizes(L*W*H), product weighing range(min and max weight), speed(how many bags per hour), rejector needed or not so that we can select the best suitable check weigher for you.

    Q:Where are your products distributed?

    A:Our products are distributed all over the world,main markets are Europe,North America, South America, the united Arab emirates, Africa and so on.

    Q: How about your after-sales policy?

    A: Timely, efficient, customer first

    (1) One-year warranty (life-time service)

    (2) Online support and professional video guidance

    (3) Complete training course, either in Eagle or through the internet


    Package


    Machines are film wrapped and fixed in the exported wooden case. All the wooden cases will be transported to departure port warehouse to wait for loading in container or directly load in the container in our factory. All based on customer’s requirements.
