Paper Bag Packing Machine 50 Pounds Fertilizer Bagging Machine In
Fertilizer Industry
Application Scope
The automatic granule packing machine adopts microcomputer control,
which is easy to operate, stable, fast and accurate; it has
functions such as precise weighing sensor, energy-saving
components, automatic error correction, etc.; It is designed to
operate in a wide range of industries such as food, feed, chemicals
and building materials. The system can be equipped with a range of
feeding devices (high-speed or standard gravity, belt, screw and
vibratory feeder).
| Transport Machine Technical Parameters |
| Conveyor Length | 3000mm |
| Conveyor Speed | 5-20m/min |
| Conveyor Belt Width | 400mm |
| Maximum Conveying Capacity | 10-15 bags / min |
| Power Supply | AC380V |
| Power | 0.75KW |
Main machine components list
| No | Name | Model | Manufacturer | QTY |
| 1 | Control system | | Canada Germaine | 1 |
| 2 | Weighing controller | | Canada Germaine | 1 |
| 3 | Weighing sensor | | Toledo | 1 |
| 4 | Approach switch | BN-M18 | Omron | 1 |
| 5 | Optoelectronic switch | FQ31-TO8P | Omron | 1 |
| 6 | Contactor & breaker | | Zhengtai | 10 |
| 7 | Other low-pressure component | | Zhengtai | 1batch |
| 8 | Motor | | Zhengjiang China | 1batch |
| 9 | Cylinder | | AIRTAC | 1batch |
| 10 | Magnetic valve | | AIRTAC | 1batch |
| 11 | Other pneumatic element | | AIRTAC | 1batch |
| Weighing Machine Technical Parameters |
| Type | 5-50kg Double Bucket Granule Packing Scale |
| Weighing Capacity | 8-15bags/min |
| Weighing Range | 5-60kg/package |
| Weighing Error | 0.2-2% |
| Control Method | Meter + Touch screen |
| Power Supply | AC380V |
| Host Power | 3KW |
| Gas Supply | oil-free, dust-free instrument gas |
| Pressure | 0.4---0.6Mpa |
Machine Main Parts
The load cell we installation 3-4pcs Toledo load cell (max weight
200kg/pc, IP67).
The bagging machine can stable working 10 years.
Our packing machine accessories all use the famous brand, such as
pneumatic element use the AirTAC,
HMI (color touch screen panel) use the Germain / Unipulse
(customized), the electric element we use the Schneider
Machine Features
♦. Reasonable mechanical structure, easy to change size parts and
clean up.
♦. We use famous brand electric, more steady .
♦. Machine working with small noisy.
♦. All machine can be made of SUS 304 material.
Installation
The installation can be provided by the EAGLE company.
During the installation session, a one day training course will be
provided to the customer for operation and maintenance procedure.
The purchase at US$100/person/day plus all local transportation,
air tickets (round trip), and hotel room & board is provided.
Day charges include travel days.
It must be after shipment has arrived and factory must ready
equipped with all necessary requirement before booking installation
with EAGLE company. Our engineers will come to the site for the
complete and final installation.
Packaging and Shipping
Clean the machine and film wrap it
Fix the bottom of the equipment
Check the accessories all packed well
Close the wooden case
Print the mark and stick it on the wooden case
Loading, entering the warehouse
Our Service
We Promise Customer Perfect Guarantee and After-Service
As for EAGLE packaging machine, our company provides 12 months for
all mechanical parts except for electrical and electronic parts and
those subjects to normal wear and tear. Meanwhile, the guarantee
starts from the shipment (B/L date). The guarantee is intended
limited to the replacement of the broken part after checking the
construction fault. The guarantee declines in the case the customer
proceeds, without proper consent, to the replacement, modification,
or repair of parts. The inspection of the causes of the trouble or
the breakdown of the parts is exclusively up to the manufacturing
company. All in all, our company can offer you assured products.
